M300F Multi-parameter Analyzer

Name: M300F Multi-parameter Analyzer
SKU: M300F
Rating: 4.8 (7 reviews)

M300F

Ion

● 1-5 points calibration.

● Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX, ppm, ppb, etc.

● Multi-measurement modes are supported, including Direct Reading mode, Standard Addition mode, Sample Addition mode

and GRAN mode.

● Over 10 methods are built-in, including F- , Cl- , Br- , I- , NO3 - , BF4 - , NH4 + , K+ , Na+ , Ca2+, Cu2+, Pb2+, Ag+ and etc., user-defined method is supported.

● 1-5 points calibration with Standard Recognition.

● Selectable pH buffer groups, including NIST, DIN, GB, USA.

● Automatic electrode diagnosis with pH slope and offset display.

Conductivity

● 1-3 points calibration with Standard Recognition.

● Settable parameters, including cell constant, temperature compensation coefficient and TDS factor.

● Temperature compensation type (none, linear, pure water).

● Support for air-saturated water or zero oxygen calibration.

● Auto barometric pressure compensation

● Manual Salinity Factor Correction.

● Selectable pressure unit, including kPa, mbar, Torr, Atm.

Enquiry

● High resolution LCD display, 5.7 inches.

● Multi-reading feature allows auto-read, timed-read and continuous-read.

● Automatic/Manual temperature compensation ensures accurate results.

● Auto-hold feature senses and locks the measurement endpoint.

● Data Storage 500 sets (GLP-compliant).

● Support for USB or RS-232 communication.

● Reset feature automatically resumes all settings back to factory default options.

● IP54 waterproof.

Model	M300F
Parameters	pH/EC/ISE/DO/Temp. (mV/ORP/pX/Resistivity/TDS/Sal./DO Saturation)
pH	Range	-2.00 to 20.00pH
	Resolution	0.1, 0.01,pH
	Accuracy	±0.01 pH
	Calibration Points	Up to 5
	Standard Customization	Yes
	Standard Recognition	NIST, GB, DIN buffers
	Slope Limit	Yes
mV/ORP	Range	-2000.0 to 2000.0 mV
	Resolution	0.1 mV
	Accuracy	± 0.3 mV or ± 0.1%
pX	Range	-2.00 to 20.00 pX
	Resolution	0.1, 0.01pX
	Accuracy	±0.01 pX
	Calibration Points	Up to 5
ISE	Range	1.000e-9 to 9.999e+9
	Units	mol/L, mmol/L, g/L, mg/L, μ g/L, ppm, ppb
	Resolution	Up to 4 significant digits
	Accuracy	± 0.3%
	Calibration Points	Up to 5
Conductivity	Range	0.000 μS/cm to 2000 mS/cm
	Resolution	0.001 μS/cm minimum, various with range selection
	Accuracy	±1.0% FS
	Reference Temperature	20, 25 ºC
	Calibration Points	Up to 3
	Standard Recognition	84 μ S/cm, 1413 μ S/cm, 12.88mS/cm
Resistivity	Range	5.00 Ω·cm~20.00 MΩ·cm
	Resolution	0.01 Ω·cm minimum
	Accuracy	±1.0% FS
TDS	Range	0.00ppm~300 ppt
	Resolution	0.01mg/L minimum, various with range selection
	Accuracy	±1.0% FS
Salinity	Range	0.0 ～ 80.0 ppt
	Resolution	0.1ppt
	Accuracy	± 2ppt
Dissolved Oxygen Concentration - Polarographic	Range	0.00 to 20.00 ppm
	Resolution	0.01 ppm
	Accuracy	± 0.10 ppm
	Calibration Points	Air-saturated water or zero point
	Barometric Compensation	Yes
	Manual Salinity Factor Correction	Yes
% Saturation -Polaro- graphic	Range	(0.0 to 200.0)%
	Resolution	0.1%
	Accuracy	± 2.0%
Temperature	Range	-5 to 110 ºC, 23 to 230 ºF
	Unit	ºC, ºF
	Resolution	0.1
	Accuracy	±0.2
Measurement	Reading Mode	Auto Read (Fast, Medium, Slow), Timed, Continuous
	Reading Prompts	Reading, Stable, Locked
	Temp. Compensation	ATC, MTC
Data management	Data Storage	500 results each
Data management	GLP Features	Yes
Inputs	pH Electrode	BNC(Q9)
	DO with Temp. Probe	4-pin aviation connector
	Conductivity with Temp. Probe	5-pin aviation connector
Outputs	USB	PC
Outputs	RS 232	printer
Display options	Backlight	Yes
	Auto Shutdown	1~60 min, off
	IP Rating	IP54
	Date and Time	Yes
General	Power	AC Adapter, 100-240V AC input, DC9V output
	Dimensions	242×195×68mm
	Weight	900g (1.98 lb)
