LXXG Irrigation Water Meter

Supplied conditions

• Size:DN50~DN600
• Material: Cast iron shell
• Temperature grade: T30, T50, T90
• Pressure class: MAP16, MAP10
• Pressure loss: △P63

• Small transmission resistance, large flow capacity, anti blocking and strong anti pollution ability.
• Horizontal rotor, dry, magnetic coupling drive.
• The counter adopts vacuum sealing, anti condensation and atomization, and can keep the reading clear for a long time.
• Removable structure is adopted for easy installation and maintenance
• The measuring mechanism has strong universality.
• According to customers' needs, remote transmission and transmission device (double reed / hall transmission) can be provided.
