Leeb342 Ultrasonic Thickness Gauge

Name: Leeb342 Ultrasonic Thickness Gauge
SKU: Leeb342
Rating: 4.8 (5 reviews)

Leeb342

Measuring range(mm):0.7~300

Resolution(mm):0.01

Accuracy(mm):±(0.5%H+0.01) H refers to the thickness of testing piece

Velocity range(m/s): 1000~9999

Operating temperature: -10°C~60°C

Dampness: 20%~90%

Storage: 2000 Groups

Power supply: Rechargeable Lithium battery

Enquiry

Function & Feature:

High stability and precision.
Available software for PC connection, data transmission & analysis, and printing measurement reports.
With built-in thermal printer.
Rechargeable Li-ion battery, available for 10 hours working continuously.
Measuring sound velocity: according to the known thickness of the object, sound velocity of it can be measured directly.

Measuring Materials
Adapted to all kinds of materials which are good conductor of ultrasonic wave, such as metals(steel, cast iron, aluminum, copper and etc), plastic, ceramics, composites, epoxies, glass and etc.

Technical Specification

Model	Leeb342
Measuring range(mm)	0.7~300
Resolution(mm)	0.01
Accuracy(mm)	±(0.5%H+0.01) H refers to the thickness of testing piece
Velocity range(m/s)	1000~9999
Operating temperature	-10°C~60°C
Dampness	20%~90%
Storage	2000 Groups
Power supply	Rechargeable Lithium battery
Printer	Build-in High-speed Thermal Printer, Width of printer paper:56.5±0.5mm
Weight	400g
Dimensions	230×86×46mm
