M500T-A Multi-parameter Analyzer

Name: M500T-A Multi-parameter Analyzer
SKU: M500T-A
Rating: 4.8 (4 reviews)

M500T-A

● 1-6 points calibration with Standard Recognition.

● Selectable pH buffer groups, including DIN, NIST, USA, MERK,JIS, GB.

● Support for pH standard group customization.

● Automatic electrode diagnosis with pH slope and offset display.

Ion

● 1-6 points calibration.

● Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX,

ppm, ppb, etc.

● Multi-measurement modes are supported, including Direct Reading

mode, Standard Addition mode, Sample Addition mode and GRAN

mode.

Conductivity

● 1-5 points calibration with Standard Recognition.

● Settable parameters, including cell constant, reference

temperature (5/10/15/18/20/25°C), temperature compensation

coefficient and TDS factor.

● Temperature compensation type (none, linear, pure water).

Enquiry

● Color High contrast LCD touchscreen, 7.0 inches.
● Intelligent operation system provides features including user management, calibration management, method management, data management and etc.
● Multi-reading feature allows auto-read, timed-read and continuous-read.
● Automatic/Manual temperature compensation ensures accurate results.
● Data Storage 1000 sets for each parameter (GLP-compliant).
● Data analysis feature helps user review, compare and recalculate results.
● Support for USB or RS-232 communication.
● Reset feature automatically resumes all settings back to factory default options.
● IP54 waterproof.

Model	M500T-A
Parameters	pH/EC/ISE/DO/Temp. (mV/ORP/pX/Resistivity/TDS/Sal.)
pH	Range	-2.000 to 20.000pH
	Resolution	0.1, 0.01, 0.001pH
	Accuracy	±0.002 pH
	Calibration Points	Up to 6
	Standard Customization	Yes
	Calibration Reminder	Yes
	Standard Recognition	NIST, GB, DIN buffers
	Slope Limit	Yes
mV/ORP	Range	-2000.00 to 2000.00 mV
	Resolution	0.1, 0.01 mV
	Accuracy	reading whichever is greater
	EH ORP Mode	Yes
	ORP Calibration Points	1 custom point (relative mV)
pX	Range	-2.000 to 20.000 pX
	Resolution	0.1, 0.01, 0.001 pX
	Accuracy	±0.002 pX
	Calibration Points	Up to 6
ISE	Range	1.000e-9 to 9.999e+9
	Units	mol/L, mmol/L, g/L, mg/L, μ g/L, ppm, ppb
	Resolution	Up to 4 significant digits
	Accuracy	± 0.3%
	Calibration Points	Up to 6
Conductivity	Range	0.000 μS/cm to 2000 mS/cm
	Resolution	0.001 μS/cm minimum, various with range selection
	Accuracy	±0.5% FS
	Reference Temperature	5, 10, 15, 18, 20, 25 ºC
	Calibration Points	Up to 5
	Calibration Reminder	Yes
	Standard Recognition	10 μ S/cm, 84 μ S/cm, 500 μ S/cm, 1413 μ S/cm, 12.88 mS/cm; 146.5 μ S/ cm, 1408 μ S/cm, 12.85mS/cm, 111.3mS/cm
Resistivity	Range	5.00 Ω·cm~100.0 MΩ·cm
	Resolution	0.01 Ω·cm minimum
	Accuracy	±0.5% FS
TDS	Range	0.000~1000 ppt
	Resolution	0.001 ppm minimum, changed with range
	Accuracy	±0.5% FS
Salinity	Type	NaCl
	Range	0.0 ～ 80.0 ppt
	Resolution	0.1ppt
	Accuracy	± 1ppt
Temperature	Range	-10 to 135 ºC, 14 to 275 ºF
	Unit	ºC, ºF
	Resolution	0.1
	Accuracy	±0.1
Measurement	Reading Mode	Auto Read (Fast, Medium, Slow), Timed, Continuous
	Reading Prompts	Reading, Stable, Locked
	Temp. Compensation	ATC, MTC
Data management	Data Storage	1000 Groups
	GLP Features	Yes
	Log Management	Yes
Inputs	pH Electrode	BNC(Q9)
	DO with Temp. Probe	4-pin aviation connector
	Conductivity with Temp. Probe	5-pin aviation connector
Outputs	USB	USB 2.0 flash memory device, PC,scanner,
Outputs	RS 232	printer,auto-sampler
Display options	Backlight	Yes
	Auto Shutdown	1~60 min, off
	IP Rating	IP54
	Date and Time	Yes
General	Power	AC Adapter, 100-240V AC input, DC24V output
	Dimensions	220×195×68mm
	Weight	950g (2.09 lb)
