Gas Analysis

Name: Gas Analysis
SKU: AMC2000
Rating: 4.8 (44 reviews)

AMC2000

Accuracy: ±3%F.S.
Repeatability: 0.5%F.S.
Response time :≤2s
Power supply: 24V DC
Output: RS485/analog voltage
Working pressure range: 0.15～0.35MPa
Standard calibration gas: Air (standard condition)
Communication interface: DB9 male
Power consumption: ≤3W
Mechanical interface: 2-G 1/4
Net weight: 269g

Enquiry

AMC2000 gas mass flow controller is a device that precisely measures and controls the mass flow of gas. The sensor uses a self-developed MEMS mass flow chip, which has the characteristics of precision, stability, high and low temperature resistance, good linearity, and fast response time.Before delivery, the range, accuracy, repeatability, response time, etc.of AMC2000 are strictly tested and calibrated.

Supports multiple gas monitoring, measurement and control
Standard Modbus-RTU communication
Good repeatability, configurable parameters
Digital/analog dual optional control interface

Technical Data

Model	AMC2000R00	AMC2000R01	AMC2000R02	AMC2000R03	AMC2000R04
Range	100mL/min	300mL/min	500mL/min	1L/min	5L/min
Accuracy	±3%F.S.
Repeatability	0.5%F.S.
Response time	≤2s
Power supply	24V DC
Output	RS485/analog voltage
Working pressure range	0.15～0.35MPa
Standard calibration gas	Air (standard condition)
Communication interface	DB9 male
Power consumption	≤3W
Mechanical interface	2-G 1/4
Net weight	269g

AMC2000 Mass Flow Meter

AMC2000 is a mass flow controller used to monitor and control dry,clean, non-corrosive gases such as air, nitrogen, and oxygen (except flammable and explosive gases). It can be widely used in mass flow con-trol monitoring in universities, scientific research, fire protection, environmental monitoring, tobacco, smart agriculture, food, medicine andother industries.

AMC2000 Mass Flow Meter
