The SX-JCQ-6 sampler is an efficient micro-porous inhalation sampler based on the Anderson impact fifth-level principle.
The instrument's suction device uses a multi-hole sampling head to directly inhale microbial particles through micro-pores onto an agar plate, and the number of colonies is confirmed through colony culture.
Inside the SX-JCQ-6, there is an efficient centrifugal fan and flow sensor, maintaining a sampling flow rate of 100L/min±5%. When external factors affect the flow rate, the instrument automatically adjusts to ensure stable flow.
Since microbial and dust particle contamination can impact production and process flows, the demand for environmen tal microbial (dust) detection has been increasing. Microbial monitoring is particularly important in industries such as pharmaceuticals, food, hospitals, cosmetics, and environmental protection.
The professional airborne bacterial sampling head of the SX-JCQ-6 is made of anodized aluminum alloy, ensuring compliance with ISO 14698-1 technical standards. The surface is smooth and clean, and it features professional laser drilling with Φ0.7mmx397 holes, ensuring a particle
velocity of 10.8m/s, which captures particles larger than 1um
Function
- Provides a stable flow of 100L/min ± 5%
- 4.3 inch touch screen, simplified operation
- The flow regulator ensures the sampling flow
- Φ 0.7mm x 397 holes to ensure the impact rate reaches 10.8m/s
- Complies with ISO 14698-1/2 standard
